Technical Specifications
Full specification data for the Wuxi Suntech Power Co Ltd STP505S-H54-Nth+. Contact the manufacturer directly for the most current, verified figures.
| Brand | Wuxi Suntech Power Co Ltd |
|---|---|
| Model | STP505S-H54-Nth+ |
| Wattage | 505W |
| Dimensions (W × H) | 1134mm × 1961mm |
| NOCT | Not available |
| Temperature Coefficient | -0.29/°C |
| Product Warranty | 25 Year Product Warranty, 30 Year Performance Warranty |
| Manufacturer Logo |  |
| Product Image |  |
Performance & Electrical Specifications
Guaranteed minimum power output over the 25-year warranty period. Year 1 drops to 97.5% (light-induced degradation), then degrades at approximately 0.73%/year.
Electrical Specifications STC: 1000 W/m² · 25°C · AM1.5
| Open Circuit Voltage (Voc) | 40.33 V |
|---|---|
| Max Power Voltage (Vmpp) | 33.50 V |
| Short Circuit Current (Isc) | 15.91A |
| Max Power Current (Impp) | 15.07A |
| Temperature Coefficient (Voc) | -0.25%/°C |
| Max Series Fuse Rating | 35A |
Disclaimer: Solar Proof endeavours to maintain accurate product information but does not guarantee the correctness of any specifications shown. Contact Wuxi Suntech Power Co Ltd directly for verified, current data.
